Since Red 16Line provides both DigiLink and Thunderbolt connections, it’s now easier than ever to switch from Pro Tools HD to a second DAW, without the need to reconfigure option cards in the interface. Simply change the host mode either in the remote-control software or on the device front panel and change DAWs in seconds.
With dual-port Dante connectivity, you will be able to expand your studio over Ethernet for more channels at higher sample rates, anywhere in your network, at lower latency and lower cost.
Comes with free Brainworx bx_console_Focusrite SC plug-in
This awesome plug-in recreates the analog signal paths of Focusrite’s revered ISA 110 and ISA 130 modules, which were a part of the Focusrite Studio Console. Designed and coded by the DSP geniuses at acclaimed software house Brainworx, the new bx_console Focusrite VST/AU/AAX plug-in for Mac and PC faithfully captures the sound, feel and styling of the original iconic hardware.
If you purchased any Red, RedNet or ISA solution from January 2020 on, you will have the plug-in available in your Focusrite account as long as you’ve registered your product.
NOTE: The Focusrite Red range of Thunderbolt, Pro Tools | HD and Dante interfaces are now compatible with PCs running Windows 10 with the appropriate Thunderbolt 3 hardware.
- Two high-quality preamps
- Two dedicated XLR and two dedicated TRS inputs
- Extensive analog I/O
- Up to 64 I/O
- Dante connectivity
- Inputs
- Total inputs: 86
- Analog inputs:20
- Digital inputs: 66
- Mic preamps:2
- XLR/TRS combo jacks:0
- XLR only jacks:2
- 1/4” only jacks:2
- DB25:16
- S/PDIF in: 2
- ADAT/optical in:16
- RCA in:0
- AES/EBU:0
- MADI:0
- Dante:32
Outputs
- Total outputs: 68
- Analog outputs:18
- Digital outputs:50
- XLR out:0
- 1/4” out:2
- DB25:16
- S/PDIF out: 2
- ADAT/optical out:16
- RCA out:0
- AES / EBU:0
- MADI: 0
- Dante:32
Other Connectivity
- Connections:Thunderbolt 3, DigiLink
- MIDI I/O:In/Out
- Headphone output(s):2
- Word-clock I/O:Yes
Onboard Features
- Computer platform:Mac, Windows
- Phantom power:Yes
- Direct monitoring:Yes
- Onboard DSP:Yes
- Metering:Yes
- Display:Not Specified
- Latency control:Yes
- Monitor control:Rotary
- Headphone control:Rotary
Other
- Rack-mountable:Yes
- Included software:Yes
